Pneumatic Actuator Double Flange Butterfly Valve

Product Description

A pneumatic actuator operated double flange butterfly valve is a type of valve that uses compressed air to drive a piston or diaphragm within an actuator, which in turn opens or closes a butterfly valve. The butterfly valve has a circular disc or plate with a pivot in the center that rotates to control the flow of fluid or gas through the valve.

The double flange butterfly valve is designed with flanges on both sides of the valve body, which can be bolted to the pipeline to provide a secure and leak-proof connection. This type of valve is commonly used in industrial applications where there is a need for precise and reliable flow control, and where manual operation is not practical or feasible.

When the pneumatic actuator receives a signal, it directs compressed air into the actuator, causing the piston or diaphragm to move, which rotates the butterfly valve to the open or closed position. It is ideal for applications where quick on-off control is required or where a throttling action is needed.

The combination of a pneumatic actuator and a double flange butterfly valve results in a reliable and robust solution that provides accurate flow control and a leak-proof seal, making it suitable for use in demanding environments where safety, reliability, and performance are critical factors. These valves are used in a wide range of industries such as oil and gas, chemical processing, water treatment, and power generation.
